Product Description
1x4 Fiber optic ABS box type PLC splitter with 0.9mm SC/APC
Key Features
Compact package –Convenient for Small Application & High Density Areas
Telcordia GR-1209 & GR-1221-CORE Compliant
Jacketing Material Rated to -40 to +85 °C Operating Temperature
Bend Insensitive G657A fiber
Low Insertion Loss and PDL
High Polarization Extinction Ratio & Excellent Uniformity
Offer Unique Designs and Configuartions & Support Industry Standard Applications
Applications
FTTx Deployments(GPON/BPON/EPON)
CCTV/CATV Links
Access/Metro Networks
Long Haul Telecommunications
1×N PLC Splitter Specifications
| Ports |
1×2 |
1×4 |
1×8 |
1×16 |
1×32 |
1×64 |
| Operating Wavelength (nm) |
1260~1650 |
| Insertion Loss (dB) |
Max(P/S) |
3.8/4.0 |
7.1/7.3 |
10.2/10.5 |
13.5/13.7 |
16.5/16.8 |
20.5/21.0 |
| Loss Uniformity (dB) |
Max |
0.6 |
0.6 |
0.8 |
1.2 |
1.5 |
2.5 |
| PDL (dB) |
Max |
0.15 |
0.15 |
0.25 |
0.3 |
0.3 |
0.3 |
| Return Loss (dB) |
Min |
UPC:50 APC:55 |
| Directivity (dB) |
Min |
55 |
| Standard Input Fiber |
Bend Insensitive SM Single Fiber(ITU G.657A) |
| Standard Output Fiber |
Bend Insensitive SM Ribbon Fiber(ITU G.657A) |
| Standard Output Color |
Blue,Orange,Green,Brown,Grey,White,Red,Black(TIA/EIA 598-B) |
| Max.Optical Power(mw) |
300 |
| Humidity Range(rh) |
5%~85% |
| Operating Temperature(°C) |
-40~+85 |
| Storage Temperature(°C) |
-40~+85 |
| Connector Options |
FC/SC/LC/ST/MU/E2000 |
| Packaging Options |
Bare Device*Mini Tube*ABS Module*LGX Box*19''/23'' Rack-mount |
|
*Telcordia GR-1221-CORE&G-1209-CORE Compliant.
*Premium spec available upon request. (P/S:Premium Grade/Standard Grade)
*Typical value at +23°C without connectors losses.
|
Our Company
Shenzhen Optfocus Technology Co.,Ltd was established in 2009, OPTFOCUS is a High -tech enterprise, professional R & D, production and sales of Fiber to the Home (FTTH), Fiber to the Building (FTTB) & FTTx, Fiber access network equipment and terminal equipment & cabling system products. It is committed to provide Customized OEM & ODM services to Global communication distributors, Telecom Operators and System Integrators.
Our Service
OPTFOCUS TECHNOLOGY Service Online/Offline
A.Payment Terms
1) PAYPAL, Western Union, T/T for samples
2) ESCROW, Ali-Secure, L/C, OA are negotiable
3) Drop-shipping available; Agent/Proxy are welcome!
B. Any inquiried will be replied within 24 hours
C. Professional manufacturer; Welcome to visit our website
D. OEM/ODM service available
E. High quality, reasonable/competitive price, fast lead time
F. After-sale Service
